MTO-065T Slewing Bearings(65x135x22mm) (2.559x5.315x0.866inch) Without Gear TMP Band turntable bearing

    Buy cheap MTO-065T Slewing Bearings(65x135x22mm) (2.559x5.315x0.866inch) Without Gear TMP Band turntable bearing from wholesalers

    Buy cheap MTO-065T Slewing Bearings(65x135x22mm) (2.559x5.315x0.866inch) Without Gear TMP Band turntable bearing from wholesalers
    • Buy cheap MTO-065T Slewing Bearings(65x135x22mm) (2.559x5.315x0.866inch) Without Gear TMP Band turntable bearing from wholesalers

    MTO-065T Slewing Bearings(65x135x22mm) (2.559x5.315x0.866inch) Without Gear TMP Band turntable bearing

    Ask Lasest Price
    Brand Name : TMP
    Model Number : MTO-065T
    Certification : ISO9001:2008
    Price : 1-1000
    Delivery Time : 10 days
    Payment Terms : T/T
    Supply Ability : 1000 pcs/month
    • Product Details
    • Company Profile

    MTO-065T Slewing Bearings(65x135x22mm) (2.559x5.315x0.866inch) Without Gear TMP Band turntable bearing

    MTO-065T Slewing Bearings(65x135x22mm) (2.559x5.315x0.866inch) Without Gear TMP Band turntable bearing
    A . Slewing Bearings Parameters
    Brand-TMP
    Model number-MTO-065T
    Inner ring(in)-2.559
    Outer ring(in)-5.315
    Width(in)-0.866
    Weight(lbs)-4
    weight(kg)-1.81
    Materials-GCR15/GCR15SiMn/50Mn/42CrMo/5CrMnMo
    Series-MTO-No Gear
    Lubrication type-Grease lubrication
    Rolling elements-Ball
    Load direction-Multi-load
    Structure-Rectangular cross-section.The internal configuration consists of deep groove gothic arch raceways and maximum ball complement.
    B . MTO-065T Slewing Bearings Specification Sheet
    Part numberOutline dimensions (in)weight
    (lbs)
    Fixing holesGear data inv.
    stub, α = 20°
    Moment
    rating
    DodiHDrDidodrLo
    (in)
    noBo
    (in)
    Li
    (in)
    niBi
    (in)
    D2
    (in)
    mzFz
    (lbs)
    Crm
    (ft-lbs)
    MTO-065T5.3152.5590.866----44.7248M83.1498M8----1330

    Product

    Features

    Slewing Bearings have high load carrying capacity, a versatile range of applications and

    are highly cost-effective.Due to their design, a single bearing can reliably support radial,

    axial and tilting moment loads. It is therefore possible in many cases to replace bearing

    arrangements comprising a combination of radial and axial bearings by a single bearing.

    BYC Slewing Bearings have Two types:Four point contact slewing bearings and crossed

    roller slewing bearings.

    Series

    Introduction

    Kaydon's MT series heavy duty slewing ring bearings offer solutions for applications such

    as truck mounted cranes, hoists, and non-precision industrial tables and positioners,

    providing optimal economy and capacity for a given envelope dimension.

    Series

    Model No.

    RK6-16P1Z,RK6-22P1Z,RK6-25P1Z,RK6-29P1Z,RK6-33P1Z,RK6-37P1Z,RK6-43P1Z,

    RK6-16N1Z,RK6-22N1Z,RK6-25N1Z,RK6-29N1Z,RK6-33N1Z,RK6-37N1Z,RK6-43N1Z,

    RK6-16E1Z,RK6-22E1Z,RK6-25E1Z,RK6-29E1Z,RK6-33E1Z,RK6-37E1Z,RK6-43E1Z
    MTO-050,MTO-050T,MTO-065,MTO-065T,MTO-122,MTO-122T,MTO-143,MTO-143T,

    MTO-145,MTO-145T,MTO-145X,MTO-170,MTO-170T,MTO-210,MTO-210T,MTO-210X,

    MTO-265,MTO-265T,MTO-265X,MTO-324T,MTO-324X,MTE-145,MTE-145T,

    MTE-145X,MTE-210,MTE-210T,MTE-210X,MTE-265,MTE-265T,MTE-265X,MTE-324T,

    MTE-324X,MTE-415,MTE-415T,MTE-470,MTE-470T,MTE-540,MTE-540T,MTE-590,

    MTE-590T,MTE-705,MTE-705T,MTE-730,MTE-730T,MTE-870,MTE-870T
    KH-125P,KH-166P,KH-225P,KH-275P,KH-325P,KH-125E,KH-166E,KH-225E,KH-275E,KH-325E
    HS6-16P1Z,HS6-21P1Z,HS6-25P1Z,HS6-29P1Z,HS6-33P1Z,HS6-37P1Z,HS6-43P1Z,

    HS6-16N1Z,HS6-21N1Z,HS6-25N1Z,HS6-29N1Z,HS6-33N1Z,HS6-37N1Z,HS6-43N1Z.

    HS6-16E1Z,HS6-21E1Z,HS6-25E1Z,HS6-29E1Z,HS6-33E1Z,HS6-37E1Z,HS6-43E1Z

    Applications

    MT series slewing rings have been used successfully in a wide range of applications from

    light to heavy duty. The smaller sizes are well suited for:Manipulators,Jib cranes,

    Lift-assist devices,Work positioners

    Larger sizes are well suited for:Truck-mounted cranes,Aerial lifts,Hoists,Small wind

    turbines,Non-precision positioning tables


    Categories:Slewing Bearings
    Other Ball Bearings
    Related Search:MTO-065T Bearing,MTO-065T Slewing Bearing,MTO-065T Slewing Ring,MTO-065T Turntable Bearing,65x135x22mm Bearing
